Product Specification |
|
|
Overview |
Reyee by Ruijie RG-ES218GC-P Cloud Managed Smart Switch for IP surveillance 16 Port Gigabit, 2 SFP, จ่ายไฟ POE 16 Port มาตรฐาน 802.3af/at กำลังไฟสูงสุด 240W รองรับการ Managed และ Monitor ผ่าน Ruijie Cloud และ App ติดตั้งใน Smartphone Cloud License ฟรี ตลอดชีพ |
|
Ports |
16 10/100/1000 Base-T ports (PoE/PoE+) |
|
Maximum output power per PoE port |
30W |
|
Maximum PoE output power per switch |
240W |
|
Switching capacity |
36Gbps |
|
Packet forwarding rate |
28.784Mpps |
|
Surge protection |
Common mode: 4KV |
|
Electrostatic discharge |
Air discharge: 6KV |
|
Power consumption |
≤280W |
|
Power supply |
Built-in power supply |
|
Dimensions (W x D x H) |
300*230*43.6mm |
|
MTBF |
>200K |
|
Operating temperature |
0 to 40°C |
|
Storage temperature |
-40~70ºC |
|
Operating humidity |
10% to 90% RH |
|
Storage humidity |
5% to 95% RH |
|
MAC capacity |
8K |
|
Static MAC address |
16 |
|
VLAN |
Support 802.1Q VLAN |
|
Port management |
Support port status display, port traffic statistics, PoE port output power status, port duplex / negotiation rate configuration, flow control configuration, PoE output on/off |
|
Security |
Support broadcast storm suppression, port speed limit, port isolation |
|
L2 features |
Support port mirroring, loop protection, cable detection |
|
Management |
Support management and configuration through web management interface, Ruijie Cloud platform and Ruijie Cloud app |
Ruijie
Ruijie switch รุ่น RG-ES218GC-P Reyee Cloud Managed Switch for IP surveillance
18-Port Gigabit Smart POE Switch, 16 Gigabit RJ45 Ports including 16 POE/POE+ Ports, 2 SFP Slots, 240W PoE power budget,13-inch Rack-mountable Steel Case
3 Years Warranty
