Specification
| a System | Compression | Standard H.265 |
| OS | Embedded Linux | |
| Video | Network Input | 16 CH IPC input |
| Network Access Bandwidth | 80Mbps | |
| Network Access Format | 5MP / 4MP / 3MP / 1080P /960P /720P@25/30fps |
|
| Output | HDMI x 1: 4K x 2k / 1920 x 1080 / 1280 x 1024; HDMI-VGA cable optional, 1920 x 1080 / 1280 x 1024 |
|
| Audio | Network Input | 16 CH IPC audio input |
| 2-way Audio | No | |
| Local Output | RCA x 1 | |
| Record | Record Stream | Dual stream recording |
| Resolution | 5MP / 4MP / 3MP / 1080P/ 960P /720P | |
| Mode | Manual, timer, motion, sensor | |
| Playback | Simultaneous Playback | 4 CH Playback |
| Search | Time slice / time / event / tag search | |
| Smart Search | Highlighted color to display the camera record in a certain period of time, different colors refers to different record events |
|
| Function | Play, pause, FF, FB, digital zoom, etc. | |
| Alarm | Mode | Manual, sensor, motion, exception |
| Output | No | |
| Triggering | Record, snap, preset, e-mail, etc. | |
| Network | Interface | RJ45 10 / 100 Mbps x 1 |
| Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP |
|
| Web Client | Multiple users online | |
| Mobile Device | OS | iOS, Android |
| Storage | HDD | SATA x 2, max 6T per HDD |
| Backup | Local Backup | U disk, USB mobile HDD |
| Network Backup | Yes | |
| Port | USB | USB 2.0 x 2 ( one in the front panel and the other in the rear panel ) |
| Others | Power Supply | DC12V |
| Consumption | ≤5W ( without HDD ) | |
| Dimensions (mm) | 380 x 268 x 52 ( W x D x H) | |
| Work Environment | -10°C~ 50°C, 10% ~ 90% humidity |
