| Specifications |
| Model |
Model CS-BC1-B3 (2K⁺) |
| Camera |
| Image Sensor |
1/3″ 4-Megapixel Progressive Scan CMOS Sensor |
| Shutter Speed |
Self-Adaptive shutter |
| Lens |
2.8mm @ F1.6 Viewing angle: 116°(Diagonal), 100° (Horizontal) |
| Battery Capacity |
12900 mAh |
| Minimum Illumination |
0.2 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Lens Mount |
M12 |
| Day & Night |
IR-Cut filter with auto-switching |
| DNR |
3D DNR |
| Night Vision Distance |
Up to 32 ft / 10 m |
| Video & Audio |
| Max. Resolution |
2K⁺ / 4MP, 2560 × 1440 pixels |
| Frame Rate |
15fps. Self-Adaptive during network transmission |
| Video Compression |
H.265 / H.264 |
| Video Bit Rate |
Ultra-HD; FHD; Hi-Def. Adaptive bit rate. |
| Audio Bit Rate |
Self-Adaptive |
| Max. Bitrate |
2 Mbps |
| Camera Network |
| Wi-Fi Standard |
IEEE802.11b, 802.11g, 802.11n |
| Frequency Range |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth |
Supports 20 MHz |
| Security |
64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK |
| Transmission Rate |
11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps |
| Wi-Fi Pairing |
AP pairing |
| Protocol |
EZVIZ Cloud Proprietary Protocol |
| Interface Protocol |
EZVIZ Cloud Proprietary Protocol |
| Wired Network |
RJ45 × 1 in Base (10 M / 100 M Adaptive Ethernet Port) |
| Minimum Network Requirement |
4 Mbps |
| Storage |
| Local Storage |
Supports microSD card (Up to 256 GB) on base |
| Cloud Storage |
Supports EZVIZ CloudPlay storage (Subscription required) |
| Function |
| Smart Alarm |
Smart Human Motion Detection |
| Customized Alert Area |
Supports |
| Two-Way Talk |
Supports |
| General |
| Operating Conditions |
-20 °C to 50 °C (-4 °F to 113 °F) Humidity 95% or less (non-condensing) |
| IP Grade |
IP 66 |
| Package Dimensions |
260 × 217 × 180 mm (10.24 × 8.54 × 7.09 inch) |
| Weight (Camera) |
385 g (13.58 oz) |
| Weight (Base) |
207 g (7.30 oz) |
| Weight (With Package) |
2441 g (86.10 oz) |
| Base Station W2H-B |
| limit number of connections |
1 W2H-B supports up to 4 EZVIZ battery-powered cameras |
| Button |
Sync button, power button, reset button. |
| Indicator |
3 RGB LED indicator, 1 network indicator |
| Network Interface |
1 RJ-45 10 / 100 Mbps Self-adaptive Ethernet WAN interface |
| Wireless Interface |
Supports 2.4 G connection. The actual available channels vary according to the sales area regulations. Theoretical maximum rate is 144 Mbps at 802.11b/g/n. |
| Power |
| Power Supply |
Camera: DC 5V / 2A, Base: DC 12V / 1A |
| Power Consumption |
Max. 5W |
