- Camera
- Image Sensor2MP CMOS image sensor
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.01 Lux@(F1.2,AGC ON), 0 Lux with IR
- Shutter Time1/25 (1/30) s to 1/50,000 s
- Day & NightICR
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 – 12 mm @ F1.4
- Focal Length & FOV102.25° – 32 °
- Lens MountΦ14
- Image
- Wide Dynamic Range (WDR)>62 dB
- Interface
- Video Output1 HD analog output
- General
- Dimension92mm×84.8mm×269.6mm (3.62”×3.34”×3.34”)
- Approx. 900g (1.98lb)
- Operating Condition-40° C to 60° C (-40° F to 140° F), Humidity 90% or less (no condensation)
- Power Supply12 VDC±15%
- Consumption
Max. 4 W
- IR RangeUp to 40 m
- Approval
- ProtectionIP66
