| Camera | ||
|---|---|---|
| Image Sensor: | 1/3″ Progressive Scan CMOS | |
| Min. Illumination: | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR | |
| Shutter time: | 1/3s~1/100,000s | |
| Lens: | 4mm, horizontal view angle 63°(2.8mm/6mm/8mm optional) | |
| Lens Mount: | M12 | |
| Adjustment Range: | H: -30°~30°, V: 0°~80°, R: 0°~360° | |
| Day& Night: | IR cut filter with auto switch | |
| Wide Dynamic Range: | Digital WDR | |
| Digital noise reduction: | 3D DNR | |
| Compression Standard | ||
|---|---|---|
| Video Compression: | H.264/MJPEG | |
| H.264 code profile: | Base Line Profile/Main Profile | |
| Video bit rate: | 32Kbps~8Mbps | |
| Audio Compression: | G.711/G.722.1/G.726/MP2L2 | |
| Audio bit rate: | 64Kbps(G.711)/16Kbps(G.722.1)/32-128Kbps(MP2L2) | |
| Dual Stream: | Yes | |
| Image | ||
|---|---|---|
| Max. Image Resolution: | 1920 x 1080 | |
| Frame Rate: | 50Hz: 25fps (1920*1080,1280 × 960,1280 × 720) 60Hz: 30fps (1920*1080,1280 × 960,1280 × 720) |
|
| Image Settings: | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser | |
| BLC: | Yes, zone configurable | |
| ROI: | support | |
| 3D DNR: | support | |
| Network | ||
|---|---|---|
| Network Storage: | Micro SD/SDHC/SDXC card with ANR (up to 64G), NAS (Support NFS, SMB/CIFS) | |
| Alarm Trigger: | Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception | |
| Protocols: | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
|
| General Function: | User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask | |
| System Compatibility: | ONVIF (Profile S, Profile G),ISAPI | |
| Interface | ||
|---|---|---|
| Audio: | Internal Microphone and Speaker | |
| Communication Interface: | 1 RJ45 10M / 100M Ethernet interface | |
| On-board storage: | Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB | |
| General | ||
|---|---|---|
| Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
|
| Power Supply: | 12 V DC ± 10%, PoE (802.3at) | |
| Power Consumption: | 5.5W MAX | |
| Impact Protection: | IK08 Protection Level | |
| Weather Proof: | IP66 | |
| IR Range: | 10 meters | |
| Dimensions: | 99.3×96.7×52.8mm (3.91” × 3.81” × 2.08”) | |
| Weight: | 600g (1.32lb) | |
