| Camera | ||
|---|---|---|
| Image Sensor: | 1/3″ Progressive Scan CMOS | |
| Min. Illumination: | 0.01Lux @(F1.2,AGC ON) , 0 Lux with IR 0.028Lux @(F2.0,AGC ON) ,0 Lux with IR |
|
| Shutter time: | 1/3 s to 1/100,000 s | |
| Lens: | 4mm@ F2.0, angle of view: 73.1°(6mm, 46°; 8mm, 35.5°; 12mm, 22° optional) | |
| Lens Mount: | M12 | |
| Adjustment Range: | (Universal) H: -15°~15°, V: 0°~30°, R: -90°~90° | |
| Day& Night: | IR cut filter with auto switch | |
| Wide Dynamic Range: | Digital WDR | |
| Digital noise reduction: | 3D DNR | |
| Compression Standard | ||
|---|---|---|
| Video Compression: | H.264/MJPEG | |
| H.264 code profile: | Baseline Profile / Main Profile / High Profile | |
| Video bit rate: | 32Kbps~8Mbps | |
| Dual Stream: | Yes | |
| Image | ||
|---|---|---|
| Max. Image Resolution: | 1280×960 | |
| Frame Rate: | 50Hz: 25fps (1280 × 960), 25fps (1280 × 720),60Hz: 30fps (1280 × 960), 30fps (1280 × 720) | |
| Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser | |
| BLC: | Yes, zone configurable | |
| ROI: | support | |
| 3D DNR: | support | |
| Network | ||
|---|---|---|
| Network Storage: | NAS (Support NFS,SMB/CIFS) | |
| Alarm Trigger: | Motion detection, Tampering alarm | |
| Protocols: | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour | |
| General Function: | User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask | |
| System Compatibility: | ONVIF (Profile S, Profile G),ISAPI | |
| Interface | ||
|---|---|---|
| Audio: | Internal Microphone and Speaker | |
| Communication Interface: | 1 RJ45 10M / 100M Ethernet interface | |
| Video Output: | 1Vp-p Composite Output (75 Ω, BNC) | |
| General | ||
|---|---|---|
| Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
|
| Power Supply: | 12 V DC ± 10%, PoE (802.3at) | |
| Power Consumption: | DC12V: 7.5W MAX PoE: 9W MAX |
|
| Impact Protection: | IK10 | |
| IR Range: | Approx 20 to 30 meters(65.6-98.4ft) | |
| Dimensions: | Φ155.17 × 110.9 × 60.8mm | |
| Weight: | 846g | |
