Camera
Image Sensor: 5MP CMOS Image Sensor
Min. Illumination: Color: 0.008 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time: 1/25(1/30) s to 1/50,000 s
Lens: Motorized VF lens; 2.8 to 12 mm
Lens Mount: φ14
Adjustment Range: Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360°
Day& Night: IR cut filter with auto switch
HD Video Output: 1 Analog HD output
Synchronization: Internal Synchronization
Menu
D/N Mode: Auto / Color / B/W
Auto White Balance: Auto/MWB
BLC: Support
AGC: Support
Language: English/Chinese
Function: Brightness, Sharpness, Digital noise reduction, Mirror, Smart IR
General
Operating Conditions: -40 °C – 60 °C (-40 °F – 140 °F)
Humidity 90% or less (non-condensing)
Power Consumption: Max. 8 W
Weather Proof: IP67
IR Range: Up to 40m
Communication : Up the coax
Protocol: HIKVISION-C(Coaxitron)
Dimension: 134.3 mm × 123.9 mm × 111.4 mm (5.29″ × 4.88″ × 4.39″)
Weight: Approx. 750 g (1.57 lb.)
